Micron Liquid Filter Bag Price：￥

Online inquiry
Previous Next
Detailed content

1. Material Specifications


MaterialMax Temp. ResistanceChemical ResistanceCommon Applications
Polypropylene (PP)194°F (90°C)Acids, alkalis, solvents (general-purpose)Water treatment, food & beverage, chemicals
Nylon250°F (121°C)Oils, fuels, weak acids/alkalisHydraulic fluids, lubricants, paints
Polyester (PE)275°F (135°C)Good resistance to most solventsPharmaceuticals, coatings, high-temp liquids
PTFE500°F (260°C)Highly resistant to aggressive chemicalsCorrosive fluids, high-purity processes



2. Filtration Performance

  • Micron Ratings: 1µ, 5µ, 10µ, 25µ, 50µ, 100µ, 200µ, 300µ,400µ, 500µ+ (custom options available)

  • Filtration Efficiency: 90–99.9% (depending on micron rating and material)

  • Dirt Holding Capacity: Varies by size (typically 0.5–5 kg per bag)

  • Max Operating Pressure: 7–10 bar (100–150 psi) (varies by housing design)

  • Flow Rate: Depends on bag size and porosity (e.g., 10–200 GPM per bag)


3. Physical Dimensions

Bag Size (Diameter x Length)Standard Housing Compatibility
2" x 8" (51mm x 203mm)Small-scale lab/industrial units
4" x 10" (102mm x 254mm)Common in chemical processing
7" x 17" (178mm x 432mm)High-flow industrial systems
7" x 32" (178mm x 813mm)Large-capacity liquid filtration


4. Construction & Design

  • Seam Type:

    • Heat-sealed: Prevents bypass, ideal for fine micron filtration.

    • Stitched: Reinforced seams for heavy-duty applications.

  • Top Ring: Stainless steel, polypropylene, or nylon for secure fit.

  • Surface Treatment: Some bags feature anti-static or hydrophilic coatings.



6. Applications

  • Water Treatment: Removal of sediments, rust, and particulates.

  • Chemical Processing: Filtration of acids, solvents, and aggressive fluids.

  • Food & Beverage: Clarification of syrups, oils, and dairy product

  • Paints & Coatings: Removing impurities for smooth finishes.

  • Oil & Fuel: Contaminant removal in lubricants and hydraulic systems.
